FULL FPGA

ULTRA AHF

Compensate THDv & THDi

Response Time <=1ms

Resonance Free

View Manual

INTRODUCTION

Ultra Active Harmonic Filter

iKonMac breaks through the barrier of the lack of a complete solution to power quality issues in weak grid environments. The independently developed Ultra AHF series stable active power filters perfectly achieve the goal of jointly controlling current harmonics and voltage harmonics.

The Ultra AHF series stable active power filters feature faster response times and can more accurately avoid resonance. The most prominent advantage is the ability to simultaneously control various unstable harmonics and stabilize the power grid.

APPLICATIONS

Semiconductor Industry

THDv After Mitigation 2.3%

Supress Odd Harmonics

Even & Odd Harmonics Eliminated

Rectifier Power Supply

THDi After Mitigation 1.9%

PARAMETERS

Voltage Level304V-456V
Module CapacityActive Harmonic Filter: 100A/150A
Module Size (W*H*D)680*200*545
800*800*2200 (Max Capacity Per Cabinet)750A
Number of Parallels12
Operating Frequency50Hz (-10% ~ +10%)
Current Transformer100 : 5 ~ 10000 : 5
Controller100% Full FPGA, 16 CPUs parallel computation
Compensate For Harmonics2-50th Order Harmonics
Efficiency>98% & THDi <5%
Switching Frequency80kHz (7th Generation Infineon IGBT)
Methods of CommunicationRS485, Modbus RTU, Wifi (Remote control)
Upper Level SoftwareYes, all parameters can be set by the upper-level software
Fault AlarmYes, up to 500 alarm messages can be recorded
Monitor4.3" / 7" / 10" / 12" (Optional) Support independent monitoring of each module / centralized monitoring of the whole machine
Full Response Time<=1ms, instant response <=50us
Active Loss<=2%
Heat DissipationIntelligent air cooling
Noise<=60dB
Protection FeaturesThere are more than 20 kinds of protection such as overvoltage, undervoltage, overheating, overcurrent, short circuit, etc
CT Installation LocationLoad side
Module Weight38.5kg
Operating Temperature-20C ~ +55C
Elevation<5000 meters (More than 1000 meters, for every 100 meters of additional elevation, the power is reduced by 1%)
Relative Humidity<95%, No condensation
Ingress ProtectionModule IP20 + Electronic Layer IP42 (Customizable IP54 or IP65)
Pollution Resistance RatingLevel 2 (Customizable Level 3)

QUALITY CONTROL

IGBT Module Assembly
IGBT Module Assembly
Automatic Soldering
Automatic Soldering
Inductance Soldering
Inductance Soldering
Module Assembly
Module Assembly
Low Voltage Testing
Low Voltage Testing
High Voltage Testing
High Voltage Testing
Aging Test
Aging Test
Final Inspection
Final Inspection
Packaging
Packaging
